Walking Drive - Eaton USA
Electromagnetic valve - CAMOZZI Italy
Air compressor -Jaguar Taiwan
Cylinder - UNIQUC Japan
Two component bump line technical parameters
| Engine | Honda gasoline engine, OHV4 stroke air-cooled power 5.5HP |
| Travel drive mode | automatic hydraulic continuously variable speed |
| Working speed | 10-15m/min, maximum climbing slope |
| Marking thickness | Horizontal line |
| Bulge length | controlled by CPU intelligent program for any length |
| Hopper | pneumatic opening and closing, hydraulic stirring |
| Paint bucket | capacity 60kg * 2 |
| Double glass bead spreader | manual synchronous clutch spreader, with a capacity of 25kg * 2 |
| Rubber wheel | Iron wheel hub, specially made of heat-resistant rubber, with a locator on the rear tail wheel, allowing the vehicle to move forward in a straight line |
| Marking width | can be selected as 150/200/300/400/450mm (customizable) |
| Dimensions | length 1300 * width 1000 * height 1170mm (excluding pointers) |
| Net weight | 245kg |
Technical parameters for two-component scraping coating
| Engine | Honda gasoline engine, OHV4 stroke air-cooled power 5.5HP |
| Travel drive mode | automatic hydraulic continuously variable speed |
| Working speed | 10-15m/min |
| Maximum climbing slope | 15 ° |
| Marking thickness | Horizontal line/0-3.5mm |
| Hopper | manual opening and closing, hydraulic stirring |
| Paint bucket | capacity 60kg * 2 |
| Double glass bead spreader | manual synchronous clutch spreader, with a capacity of 25kg * 2 |
| Rubber wheel | Iron wheel hub, specially made of heat-resistant rubber, with a locator on the rear tail wheel, allowing the vehicle to move forward in a straight line |
| Marking width | can be selected as 150/200/300/400/450mm (customizable) |
| Dimensions | length 1300mm * width 1000mm * height 1170mm (excluding pointers) |
| Net weight | 296kg |
Heavsty : a scientific and technological enterprise which is engaged in the professional road marking machine research and development,design,production and sales.
