The automatic separation system of this device can suck residual water and wastewater into a vacuum chamber, and in addition, the residue can be separated from the wastewater. The residue can be automatically placed in plastic woven bags, and the wastewater will flow into the wastewater tank. When the wastewater tank is full, it will be discharged into the sewer through a water pipe. Very convenient, very safe and environmentally friendly.
| Diesel engine | WEICHAI or Cummins disel enginee four cylinder Generator 97KW |
| High pressure pump | manufactured by factory pump, pressure 140Mpa, Flow 35L/min |
| Bearing | Japan NSK, hard alloy Ø20, pump speed 530 rate/min |
| High pressure seal | Imported seal |
| Booster pump | Front booster pump with a maximum boost of 6 kilograms |
| Remove width | 150-250mm(customzied) |
| Recovery tube | length 24m, inner diameter 75mm |
| Actuator wheel width | 25cm |
| Water tank | clean water (2.5T) and sewage tank (3.5T) / Customized |
| Filter | Double layer stainless steel vertical type filter |
| Water supply protect system | Include low pressure protection system |
| Recovery system | SSR Vacuum pump, -0.4bar(Sino-Japanese joint venture) |
| Oil tank | 250L |
